Planar magnetic headphones have gained immense popularity among audiophiles due to their incredibly low distortion and lightning-fast transient response. One of the key aspects of planar magnetic driver design is the relationship between the voice coil and the magnetic field. In particular, the underhung voice coil design presents unique opportunities and challenges when it comes to optimizing flux density.
Understanding Underhung vs. Overhung Designs
In a typical headphone driver, the voice coil interacts with a magnetic gap.
– **Overhung:** The voice coil is taller (longer) than the magnetic gap. This ensures that as the coil moves, a constant number of windings remain in the gap, maintaining linear motor force over a long excursion.
– **Underhung:** The voice coil is shorter than the magnetic gap. The entire coil remains immersed in the uniform magnetic field during its excursion.
Planar magnetics inherently operate somewhat differently than traditional dynamic drivers, as the “voice coil” is a trace etched onto a thin diaphragm suspended between magnetic arrays. However, the principles of magnetic gap optimization still apply. When the traces (acting as the underhung coil) are kept completely within the uniform magnetic field (the gap created by the bar magnets), distortion is minimized significantly because the magnetic flux acting on the traces remains perfectly constant.
Optimizing Underhung Voice Coil Flux Density in Planar Magnetics – Acoustic Measurement
The Challenge of Flux Density in Underhung Designs
The primary challenge with an underhung design in planar magnetics is achieving sufficient magnetic flux density across the wider gap required to accommodate the coil’s full excursion. Because the magnetic gap must be larger than the coil’s maximum excursion, the magnetic field strength inherently drops.
Lower flux density translates directly to lower sensitivity. The driver requires more power to reach the same volume levels. To counteract this, engineers must employ strategies to optimize and maximize the flux density within that widened gap.
Strategies for Optimizing Flux Density
| Metric | Standard | Optimized |
|---|---|---|
| Frequency Response | 20Hz – 20kHz | 10Hz – 40kHz |
| THD | < 1% | < 0.1% |
| Impedance | 32 Ohms | Target Specific |
1. **High-Grade Neodymium Magnets:** The most straightforward approach is using stronger magnets. N52 grade Neodymium (NdFeB) magnets provide the highest magnetic energy product available commercially, ensuring a stronger baseline field across the gap.
2. **Symmetric Push-Pull Magnetic Arrays:** Utilizing magnet arrays on *both* sides of the diaphragm (push-pull configuration) rather than a single-sided array drastically increases the flux density and improves the uniformity of the field. This symmetric arrangement helps maintain the strict underhung geometry by creating a more sharply defined magnetic field boundary.
3. **Optimized Magnet Geometry and Spacing:** The shape and spacing of the bar magnets play a crucial role. Using Finite Element Method (FEM) software, engineers simulate different magnet cross-sections (e.g., rectangular, trapezoidal) to focus the flux lines directly onto the voice coil traces. Narrower spacing between magnets increases flux, but can obstruct airflow and cause acoustic reflections. Finding the perfect balance is critical.
4. **Flux Guides and Return Paths:** Implementing high-permeability materials (like low-carbon steel) as stators or backing plates can help guide the magnetic flux, preventing “leakage” outside the driver structure and concentrating it squarely within the gap where the diaphragm operates.
5. **Diaphragm Mass Reduction:** While not directly increasing flux density, reducing the mass of the diaphragm and voice coil traces means less force (and therefore less flux density) is required to achieve the necessary acceleration and sensitivity. Thinner substrates (like ultra-thin PET or polyimide) and highly conductive, lightweight trace materials (like pure aluminum) maximize the efficiency of the available flux.
Conclusion
Optimizing flux density in underhung planar magnetic designs is a delicate balancing act. While the underhung geometry guarantees exceptionally linear operation and low distortion by keeping the entire voice coil immersed in a constant magnetic field, it demands meticulous engineering to maintain adequate sensitivity. Through the use of advanced materials, complex magnetic arrays, and rigorous FEM optimization, modern planar magnetic headphones achieve the holy grail: pristine, low-distortion audio reproduction with efficiency levels that are increasingly friendly to portable amplification.
